志尚儀器股份有限公司

SOLARBOX 3000 / 3000e 耐光耐候試驗機桌上型

SOLARBOX 3000 / 3000e

耐光耐候試驗機桌上型

SOLARBOX xenon test chambers

廠牌:代理
供應商:大台北尖端儀器有限公司
聯絡電話:02-2531-0981
定價:與我們聯絡

快速詢價

13410

行動條碼QR Code
耐光耐候試驗機桌上型-行動條碼QR Code

SOLARBOX型是一種能夠模擬陽光照射的人工氣候試驗箱,標誌著小型光老化試驗系統方面的突破性進展。該裝置內的輻射能量由產生兩倍太陽的輻照水平的風冷式單管高級氙燈提供,輻照度與落在樣品上的光能成正比。一個環境試驗箱如果想要獲得精確的和可重現性的試驗結果必須能夠控制輻照度。

輻照度控制:

SOLARBOX試驗箱在每個試驗期間提供輻照度持續的測量與控制,通過一個閉環窄帶輻照度傳感控制系統不斷修正氙燈與UV濾片的老化處理過程。氙燈在拋物面型反光板上聚焦,這樣不用轉動樣品盤,就能保證輻照的均勻性,同樣能與轉鼓式氙燈老化曝曬系統相媲美。

溫度控制:

溫度對材料老化的影響在最終使用環境中也是一個很重要的因素,自然環境中的熱量來自陽光中紅外光部分,物體受陽光直射時的溫度總是高於其周圍環境溫度。被測樣品放置在SOLARBOX氙燈老化試驗箱裡就是模擬與太陽光線相同的照射方式,對樣品進行照射。採用黑標溫度計(BST)可連續控制和監測氙燈的輻射熱,溫度計放置在樣品盤附近。由於溫度會加速物質的老化,所以需對樣品被照射過程中的溫度進行控制,通過氙燈和過濾片的組合可達到模擬陽光的最佳效果。SOLARBOX 1500是先進的過濾型氙燈照射人工氣候試驗箱,可以模擬戶外真實的自然氣候條件。為加速實驗過程,需要逼真地模擬太陽光線。SOLARBOX試驗箱中的風冷式氙燈不僅僅可以產生紫外光,還可以模擬太陽的所有光譜成分。

產品符合標準:

1.SOLARBOX 1500型符合ISO標準;

2.溫度和輻射度的校準,以及輻射計校準均可遵循官方國家實驗室標準進行;

3.使用傳感的校準程序可快速進行再校正。

參照標準:

SOLARBOX儀器試驗條件符合以下標準ASTM,ISO,SAE,CEN,DIN,BS,UNI及用於不同領域的其它國際標準。

儀器應用範圍:

    塑料、紙品、紡織原料、食品、油漆、墨水、化妝品、建築材料、電子部件、藥品等。

主要技術參數:

SOLARBOX Model

1500

3000

電源連接:



供電電源

230Vac 10%,50/60 Hz

總輸電線

1/N/PE

電流消耗

16A(max.)

尺寸和重量:



尺寸(mm)

750×390×400

890×390×400

曝曬面積(水平試樣盤)(mm)

280×200

420×200

重量

30Kg

32Kg

可放置樣品數量(15×30mm)

大約120個

大約180個

功能特性:





風冷式單管高級氙燈:使用時間1500小時

輻照度控制與調整

調節輻射強度的旋鈕,輻照強度:250-1100W/m2

計時器、實驗時間批示器,試驗時間設定:0-999小時

可選配件或附件:





鈣鈉玻璃UV過濾片,模擬戶外曝曬

鈣鈉玻璃UV過濾片,模擬戶內曝曬



帶紅外反射塗層鈣鈉玻璃UV過濾片,模擬戶外曝曬

帶紅外反射塗層鈣鈉玻璃UV過濾片,模擬戶內曝曬

可訂製特殊規格的帶塗層UV過濾片

用於液體樣品的磁性攪動棒

帶傳感器的輻照計和溫度計:

UV 295-400nm譜帶傳感器,全波段

UV 340nm譜帶傳感器,窄帶

UV 420nm譜帶傳感器,窄帶

照明度傳感器最高可達二萬勒克斯(2Mlux)

黑標溫度傳感器(BST)








SOLARBOX 3000 standard
Tabletop xenon system for accelerated sun exposure testing equipped with:
Countdown timer up to 999 hours and hour counter.
2500 Watt air cooled lamp designed to simulate sun exposure.
Controlled system for constant irradiance.
Infinitely variable irradiance via control knob up to 1.100 W/m2 TWO SUN level region (290-800nm).
Soda-lime glass UV filter 290 nm., extra long life, to simulate outdoor exposure.
Horizontal removable sample tray, with exposure area 200 x 420 mm.
Dimensions: 890 x 390 x 400 mm.
Electrical connection to 230 Vac, 50/60 Hz, 1/N/PE.
OPTIONAL
Magnetic stirrer for mixing liquid samples during exposure.
Water-cooled specimen table for exposure of thermosensitive materials.
CUT-ON FILTERS limiting radiation of xenon lamp:
Soda-lime glass UV filter, extra long life, to simulate outdoor exposure.
Soda-lime glass UV filter, extra long life, to simulate indoor exposure.
Soda-lime glass UV filter, extra long life, to simulate outdoor exposure with Infra Red reflection coating.
Soda-lime glass UV filter, extra long life, to simulate indoor exposure with Infra Red reflection coating.



SOLARBOX 3000e enhanced model
Tabletop xenon system for accelerated sun exposure testing equipped with the following additional features:
• Microprocessor for programming cycles and end point.
• 4 lines, 20 character LCD display.
• Control and display of irradiance.
• Control and display of Black Standard Temperature.
• Up to 15 memorized test programs, free programming.
• Complete test report via RS 232 serial interface.
• Horizontal removable sample tray, with exposure area 200 x 420 mm.
• Dimensions: 890 x 390 x 400 mm.
• Electrical connection to 230 Vac, 50/60 Hz, 1/N/PE.
OPTIONAL
Flooding System for testing the weather resistance of materials for cyclic sample immersion throughout your test program.
Flooding System as part No. S410 + water temperature control.
Test chamber humidity and temperature display.
Magnetic stirrer for mixing liquid samples during exposure.
Water-cooled specimen table for exposure of thermosensitive material.
XEN 32 REPORT LEVEL software package for transfer of test parameters to PC.
XEN 32 MAINTENANCE LEVEL as part No. 570 + Solarbox calibration.
CUT-ON FILTERS limiting radiation of xenon lamp:
Soda-lime glass UV filter, extra long life, to simulate outdoor exposure.
Soda-lime glass UV filter, extra long life, to simulate indoor exposure.
Soda-lime glass UV filter, extra long life, to simulate outdoor exposure with Infra Red reflection coating.
Soda-lime glass UV filter, extra long life, to simulate indoor exposure with Infra Red reflection coating.
RECOMMENDED SPARE PARTS
Xenon superior lamp 2500 W, life time 1500 hours.
Set of 3 air filters.



MULTIMETER UV: RADIOMETER AND THERMOMETER
MULTIMETER, portable, battery operated radiometer and thermometer for check and calibration with carrying case but without sensors.
Sensor 295 – 400 nm. wide band total UV sensor.
Sensor 340 nm. narrow band.
Sensor 420 nm. narrow band.
Illuminance sensor up to 2 Mlux.
BST (Black Standard Temperature) sensor.



SOLARBOX Model
1500
1500e
3000
3000e
Electrical connection




Mains voltage
230 Vac 10%, 50/60 Hz.



Mains connection
1/N/PE



Current consumption
16 A (max.)



Measures and weight




Dimensions
750 x 390 x 400 mm.

890 x 390 x 400 mm.

Exposure area
(Horizontal Specimen Holder)
280 x 200 mm.

420 x 200 mm.

Weight
29 Kg.

31 Kg.

Number of specimen panels
(15 x 30 mm.)
more than 120

more than 180

Features




Light source: air-cooled Xenon Lamp
X
X
X
X
Adjustment and control of irradiance level
X
X
X
X
Display of current irradiance level

X


Irradiance range: from 250 to 1.100 W/m2 region (290 - 800 nm.)
X
X
X
X
BST: control of temperature level, range: up to 100°C

X

X
BST: display of current temperature value

X

X
Timer for test time setting up to 999 hours
X
X
X
X
Microprocessor control

X

X
4 lines LCD for test parameters and program menu

X

X
Bi-directional RS 232 interface for data output

X

X
Free programming of 15 tests standards

X

X
Special sensors calibration program

X

X
Options and accessories
Soda-lime glass UV filter, to simulate outdoor exposure
X
X
X
X
Soda-lime glass UV filter, to simulate indoor exposure
X
X
X
X
Soda-lime glass UV filter, to simulate outdoor exposure with Infra Red reflection coating
X
X
X
X
Soda-lime glass UV filter, to simulate indoor exposure with Infra Red reflection coating
X
X
X
X
SPECIAL tailored to specifications UV coated filters
X
X
X
X
Flooding system for specimen
X
X
X
X
Water cooled specimen table
X
X
X
X
Test chamber humidity and temperature display
X
X
X
X
Magnetic stirrer for liquid samples
X
X
X
X
XEN 32 REPORT LEVEL
X
X
X
X
XEN 32 MAINTENANCE LEVEL data transfer and calibration software using our radiometer

X

X
Cooling unit, air refrigerator to reduce test temperature
X
X
X
X
Radiometer and thermometer with sensors:
X
X
X
X
Sensor 295-400 nm. wide band total UV
X
X
X
X
Sensor 340 nm. narrow band
X
X
X
X
Sensor 420 nm. narrow band
X
X
X
X
Illuminance sensor up to 2 Mlux
X
X
X
X
Black Standard Temperature sensor
X
X
X
X
